Series 1.4
AVS HDMI 1.4 Extractor
Series 1.4
AVS HDMI 1.4 Extractor
Article details
Technical specifications
Labelling
Disclaimer
all brand names are registered trademarks of their owners., The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and
the HDMI Logos are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
Connections
Connection 2, type
Toslink male
Input, type
HDMI™ female (Type A)
Output, type
HDMI™ female (Type A)
Output 2, type
Toslink male
Output 3, type
3.5 mm female (3-pin, stereo)
Connection, type
HDMI™ female (Type A)
Signal transmission
max. transmission rate
10.2 Gbit/s
Max. resolution
4K/30Hz (3840x2160) UHD
Supported video standards
4K/30Hz (3840x2160) UHD, 1080p (60Hz) Full HD, Full HD 1080i (60Hz), 3D
supported audio standards
Dolby Atmos, Dolby Digital HD (DTS HD), Dolby Digital TrueHD, Dolby Digital 5.1 (AC-3), Dolby 5.1, Dolby 7.1, LPCM, Stereo, Audio Return Channel (ARC)
General
Goobay Version
1.4
Color
black
Markings
CE, WEEE
Operating temperature from
0 °C
Operating temperature up to
40 °C
Packaging type
Bulk
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
Length
68.5 mm
Width
60.5 mm
Height
20 mm
Weight
97 g
Scope of delivery
Scope of delivery
manual, power supply
Packing units:
1 / 50
Item: 79138
EAN: 4040849791383
