Product and packaging similar. Subject to modifications and errors.
YUV Component Cable
RCA cable for YUV image transmission
Maximize the potential of your display screen. The YUV component cable separates each piece of color information into two components which are luminance (luminous intensity, luma), and chrominance (color component, chroma). Due to multiple signal shielding, pure materials, and precise workmanship this cable transmits any analog video signal picture for picture with low noise, color fidelity, and clarity.
- 75 Ω defined characteristic impedance
- pure copper conductor and 2-way shielding for clear signal quality
- 24 carat gold-plated contacts for minimum transmission resistance
Connections
| Connection, contact material |
gold (24 kt) |
| Connection, housing material |
ABS, PVC |
| Connection, shielding |
yes |
| Connection, length |
39.8 mm |
| Kink protection |
both sides |
| Connection 2, type |
3 RCA male (YUV/RGB) |
| Connection, type |
3 RCA male (YUV/RGB) |
Cable
| Cable length |
1 m |
| Type 2, shielding |
braid (copper) 64x |
| Ferrite core |
no |
| Cable type |
round cable |
| Inner conductor material |
CU (copper) |
| AWG |
24 |
| Material cable sheath |
PVC |
Signal transmission
| Impedance |
75 Ω |
| Signal amplification |
no |
| Capacity |
60 pF |
| max. bandwidth |
10 MHz |
General
| Packaging type |
Retail Box |
| Operating temperature from |
-10 °C |
| Operating temperature up to |
80 °C |
Dimensions / Weight
| Consumption Unit |
1 pc. in cardboard box |
