YUV Component Cable
RCA cable for YUV image transmission
YUV Component Cable
RCA cable for YUV image transmission
Article details
Maximize the potential of your display screen. The YUV component cable separates each piece of color information into two components which are luminance (luminous intensity, luma), and chrominance (color component, chroma). Due to multiple signal shielding, pure materials, and precise workmanship this cable transmits any analog video signal picture for picture with low noise, color fidelity, and clarity.
- 75 Ω defined characteristic impedance
- pure copper conductor and 2-way shielding for clear signal quality
- 24 carat gold-plated contacts for minimum transmission resistance
Technical specifications
Connections
Connection, type
3 RCA male (YUV/RGB)
Connection, length
39.8 mm
Connection, housing material
ABS, PVC
Latch protection
no
Connection 2, type
3 RCA male (YUV/RGB)
Connection, contact material
gold (24 kt)
Connection, shielding
yes
Kink protection
both sides
Cable
Material cable sheath
PVC
Cable length
7.5 m
Cable type
round cable
Inner conductor material
CU (copper)
Type 2, shielding
braid (copper) 64x
AWG
24
Ferrite core
no
Signal transmission
Signal amplification
no
Capacity
60 pF
Impedance
75 Ω
max. bandwidth
10 MHz
General
Operating temperature from
-10 °C
Operating temperature up to
80 °C
Packaging type
Retail Box
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
warranty
Warranty
10 years
Downloads
Item: 70426
EAN: 4040849704260
