Product and packaging similar. Subject to modifications and errors.
CLICK C miniDP/DP (Displayport) 0300
4K/60Hz
Connections
| Connection, housing material |
ABS, PVC |
| Connection, type |
DisplayPort™ male |
| Connection 2, type |
Mini DisplayPort male |
| Connection, contact material |
gold (24 kt) |
| Connection, shielding |
yes |
| Kink protection |
both sides |
Cable
| Material cable sheath |
PVC |
| LSZH compliant |
no |
| Cable length |
3 m |
| Cable type |
round cable |
| Inner conductor material |
CU (copper) |
| Cable sheath diameter (approx.) |
5 mm |
| Type 1, shielding |
braid (copper) 64x |
| AWG |
32 |
| Ferrite core |
no |
Signal transmission
| Signal amplification |
no |
| Max. resolution |
4K/60Hz (3840x2160) UHD |
| max. transmission rate |
10.2 Gbit/s |
General
| Markings |
WEEE, CE |
| Operating temperature from |
-10 °C |
| Operating temperature up to |
80 °C |
| Packaging type |
Retail Box |
Dimensions / Weight
| Consumption Unit |
1 pc. in cardboard box |
warranty
