Goobay
PIR motion sensor
flush-mounted ceiling mounting; 360° detection, 6 m range, indoor use (IP20), suitable for LEDs; triple infrared
Goobay
PIR motion sensor
flush-mounted ceiling mounting; 360° detection, 6 m range, indoor use (IP20), suitable for LEDs; triple infrared
Article details
  • triple sensor for more range and extra accurate detection
  • especially designed for indoor lighting, lamps, LEDs, etc.
  • accurate detection of people and animals in darkness or twilight
  • multi adjustable sensor for optimal detection setup
  • designed for the easy and quick ceiling mounting
Technical specifications
Connections
Connection, type
Screw clamp
Performance
minimum load
1
sensor type
passive infrared (PIR)
switching power
300 W
operating voltage
230 V (AC)
max view angle
360 °
max. detection range
6 m
switch-off delay from
10 s
switch-off delay to
420 s
Installation height from
2.2 m
Installation Height up to
4 m
Light sensitivity from
3 lx
light sensitivity up to
2000 lx
General
Packaging type
Retail Box
Consumption Unit
1 pc. in cardboard box
protection class
IP20
Color
white
Markings
CE, WEEE, Haus
Height
54.8 mm
Diameter
90 mm
Weight
100 g
€24.99 RRP
Packing units:
1 / 50
Item: 96007
EAN: 4040849960079
